Media Gateway

Media Gateway from Technica Engineering is a development tool for testing and analyzing onboard vehicle networks. Media Gateway features 3 x in-built automotive Ethernet switches, which means it can offer many ISO/OSI Layer 2 functions. It is the right fit for subsystem testing stations and can also be installed in a test vehicle without complications.

Jetz bestellen

Key facts

12 Broadcom 100BASE-T1 ports (100 MBit/s full duplex on a single unshielded twisted pair)

3 Gigabit Ethernet ports

1 SFP Gigabit Ethernet port

Automotive Tyco MQS connectors for 100BASE-T1 and power supply

19 status LEDs

Robust, galvanized sheet steel housing

Power requirement: 8 to 16 V DC, power consumption: 8 Watt

Size: 195 x 143 x 33 mm

Features

Single/Double VLANs
